3.14.11. 3.12.11 The canvas element

Categories
Embedded content .
Contexts in which this element may be used:
Where embedded content is expected.
Content model:
Transparent .
Element-specific attributes:
width
height
DOM interface:
interface HTMLCanvasElement : HTMLElement {
         attribute unsigned long ;
         attribute unsigned long ;

           attribute unsigned long width;
           attribute unsigned long height;

  DOMString toDataURL();
  DOMString toDataURL(in DOMString type);
  DOMObject getContext(in DOMString contextId);
};

The canvas element represents a resolution-dependent bitmap canvas, which can be used for rendering graphs, game graphics, or other visual images on the fly.

Authors should not use the canvas element in a document when a more suitable element is available. For example, it is inappropriate to use a canvas element to render a page heading: if the desired presentation of the heading is graphically intense, it should be marked up using appropriate elements (typically h1 ) and then styled using CSS and supporting technologies such as XBL.

When authors use the canvas element, they should also provide content that, when presented to the user, conveys essentially the same function or purpose as the bitmap canvas. This content may be placed as content of the canvas element. The contents of the canvas element, if any, are the element's fallback content .

In interactive visual media with scripting enabled , media, if the canvas element is with script ,the canvas element represents an embedded element with a dynamically created image.

In non-interactive, static, visual media, if the canvas element has been previously painted on (e.g. if the page was viewed in an interactive visual medium and is now being printed, or if some script that ran during the page layout process painted on the element), then the canvas element must be treated as represents embedded content with the current image and size. Otherwise, the element's element represents its fallback content must be used instead.

In non-visual media, and in visual media with scripting disabled , if the canvas element's element is without script ,the canvas element represents its fallback content must be used instead.

The canvas element has two attributes to control the size of the coordinate space: width and height . These attributes, when specified, must have values that are valid non-negative integers . The rules for parsing non-negative integers must be used to obtain their numeric values. If an attribute is missing, or if parsing its value returns an error, then the default value must be used instead. The width attribute defaults to 300, and the height attribute defaults to 150.

The intrinsic dimensions of the canvas element equal the size of the coordinate space, with the numbers interpreted in CSS pixels. However, the element can be sized arbitrarily by a style sheet. During rendering, the image is scaled to fit this layout size.

The size of the coordinate space does not necessarily represent the size of the actual bitmap that the user agent will use internally or during rendering. On high-definition displays, for instance, the user agent may internally use a bitmap with two device pixels per unit in the coordinate space, so that the rendering remains at high quality throughout.

The canvas must initially be fully transparent black. Whenever the width and height attributes are set (whether to a new value or to the previous value), the bitmap and any associated contexts must be cleared back to their initial state and reinitialised reinitialized with the newly specified coordinate space dimensions.

The width and height DOM attributes must reflect the content attributes of the same name.

Only one square appears to be drawn in the following example:

  // canvas is a reference to a <canvas> element
  var context = canvas.getContext('2d');
  context.fillRect(0,0,50,50);
  canvas.setAttribute('width', '300'); // clears the canvas
  context.fillRect(0,100,50,50);
  canvas.width = canvas.width; // clears the canvas
context.fillRect(100,0,50,50);
//
only
this
square
remains

When the canvas is initialized it must be set to fully transparent black.

To draw on the canvas, authors must first obtain a reference to a context using the getContext( contextId ) method of the canvas element.

This specification only defines one context, with the name " 2d ". If getContext() is called with that exact string for its contextId argument, then the UA must return a reference to an object implementing CanvasRenderingContext2D . Other specifications may define their own contexts, which would return different objects.

Vendors may also define experimental contexts using the syntax vendorname - context , for example, moz-3d .

When the UA is passed an empty string or a string specifying a context that it does not support, then it must return null. String comparisons must be literal and case-sensitive.

Arguments other than the contextId must be ignored, and must not cause the user agent to raise an exception (as would normally occur if a method was called with the wrong number of arguments).

A future version of this specification will probably define a 3d context (probably based on the OpenGL ES API).

The toDataURL() method must, when called with no arguments, return a data: URI containing a representation of the image as a PNG file. [PNG] .

If the canvas has no pixels (i.e. either its horizontal dimension or its vertical dimension is zero) then the method must return the string " data:, ". (This is the shortest data: URI; it represents the empty string in a text/plain resource.)

The toDataURL( type ) method (when called with one or more arguments) must return a data: URI containing a representation of the image in the format given by type . The possible values are MIME types with no parameters, for example image/png , image/jpeg , or even maybe image/svg+xml if the implementation actually keeps enough information to reliably render an SVG image from the canvas.

Only support for image/png is required. User agents may support other types. If the user agent does not support the requested type, it must return the image using the PNG format.

User agents must convert the provided type to lower case before establishing if they support that type and before creating the data: URI.


Arguments other than the type must be ignored, and must not cause the user agent to raise an exception (as would normally occur if a method was called with the wrong number of arguments). A future version of this specification will probably allow extra parameters to be passed to toDataURL() to allow authors to more carefully control compression settings, image metadata, etc. Security: To prevent information leakage , the toDataURL() and getImageData() methods should raise a security exception if the canvas has ever had an image painted on it whose origin is different from that of the script calling the method.

3.14.11.1. 3.12.11.1. The 2D context

When the getContext() method of a canvas element is invoked with 2d as the argument, a CanvasRenderingContext2D object is returned.

There is only one CanvasRenderingContext2D object per canvas, so calling the getContext() method with the 2d argument a second time must return the same object.

The 2D context represents a flat cartesian Cartesian surface whose origin (0,0) is at the top left corner, with the coordinate space having x values increasing when going right, and y values increasing when going down.

interface CanvasRenderingContext2D {
  // back-reference to the canvas
  readonly attribute HTMLCanvasElement canvas;
  // state
  void save(); // push state on state stack
  void restore(); // pop state stack and restore state
  // transformations (default transform is the identity matrix)
  void scale(in float x, in float y);
  void rotate(in float angle);
  void translate(in float x, in float y);
  void transform(in float m11, in float m12, in float m21, in float m22, in float dx, in float dy);
  void setTransform(in float m11, in float m12, in float m21, in float m22, in float dx, in float dy);
  // compositing
           attribute float globalAlpha; // (default 1.0)
           attribute DOMString globalCompositeOperation; // (default source-over)
  // colors and styles
           attribute DOMObject strokeStyle; // (default black)
           attribute DOMObject fillStyle; // (default black)
  CanvasGradient createLinearGradient(in float x0, in float y0, in float x1, in float y1);
  CanvasGradient createRadialGradient(in float x0, in float y0, in float r0, in float x1, in float y1, in float r1);
   image, DOMString repetition);
   image, DOMString repetition);

  CanvasPattern createPattern(in HTMLImageElement image, in DOMString repetition);
  CanvasPattern createPattern(in HTMLCanvasElement image, in DOMString repetition);
  // line caps/joins
           attribute float lineWidth; // (default 1)
           attribute DOMString lineCap; // "butt", "round", "square" (default "butt")
           attribute DOMString lineJoin; // "round", "bevel", "miter" (default "miter")
           attribute float miterLimit; // (default 10)
  // shadows
           attribute float shadowOffsetX; // (default 0)
           attribute float shadowOffsetY; // (default 0)
           attribute float shadowBlur; // (default 0)
           attribute DOMString shadowColor; // (default transparent black)
  // rects
  void clearRect(in float x, in float y, in float w, in float h);
  void fillRect(in float x, in float y, in float w, in float h);
  void strokeRect(in float x, in float y, in float w, in float h);
  // path API
  void beginPath();
  void closePath();
  void moveTo(in float x, in float y);
  void lineTo(in float x, in float y);
  void quadraticCurveTo(in float cpx, in float cpy, in float x, in float y);
  void bezierCurveTo(in float cp1x, in float cp1y, in float cp2x, in float cp2y, in float x, in float y);
  void arcTo(in float x1, in float y1, in float x2, in float y2, in float radius);
  void rect(in float x, in float y, in float w, in float h);
  void arc(in float x, in float y, in float radius, in float startAngle, in float endAngle, in boolean anticlockwise);
  void fill();
  void stroke();
  void clip();
  boolean isPointInPath(in float x, in float y);
  // text
           attribute DOMString font; // (default 10px sans-serif)
           attribute DOMString textAlign; // "start", "end", "left", "right", "center" (default: "start")
           attribute DOMString textBaseline; // "top", "hanging", "middle", "alphabetic", "ideographic", "bottom" (default: "alphabetic")
  void fillText(in DOMString text, in float x, in float y);
  void fillText(in DOMString text, in float x, in float y, in float maxWidth);
  void strokeText(in DOMString text, in float x, in float y);
  void strokeText(in DOMString text, in float x, in float y, in float maxWidth);
  TextMetrics measureText(in DOMString text);
  // drawing images
  void drawImage(in HTMLImageElement image, in float dx, in float dy);
  void drawImage(in HTMLImageElement image, in float dx, in float dy, in float dw, in float dh);
  void drawImage(in HTMLImageElement image, in float sx, in float sy, in float sw, in float sh, in float dx, in float dy, in float dw, in float dh);
  void drawImage(in HTMLCanvasElement image, in float dx, in float dy);
  void drawImage(in HTMLCanvasElement image, in float dx, in float dy, in float dw, in float dh);
  void drawImage(in HTMLCanvasElement image, in float sx, in float sy, in float sw, in float sh, in float dx, in float dy, in float dw, in float dh);
  // pixel manipulation
  ImageData createImageData(in float sw, in float sh);
  ImageData getImageData(in float sx, in float sy, in float sw, in float sh);
  void putImageData(in ImageData imagedata, in float dx, in float dy);
  // drawing text is not supported in this version of the API
  // (there is no way to predict what metrics the fonts will have,
  // which makes fonts very hard to use for painting)

  void putImageData(in ImageData imagedata, in float dx, in float dy, in float dirtyX, in float dirtyY, in float dirtyWidth, in float dirtyHeight);

};
interface CanvasGradient {
  // opaque object
  void addColorStop(in float offset, in DOMString color);
};
interface CanvasPattern {
  // opaque object
};
interface TextMetrics {
  readonly attribute float width;
};

interface ImageData {
  readonly attribute long int ;

  readonly attribute long int width;

  readonly attribute long int height;
  readonly attribute int[] data;
};

The canvas attribute must return the canvas element that the context paints on.

Unless otherwise stated, for the 2D context interface, any method call with a numeric argument whose value is infinite or a NaN value must be ignored.

3.14.11.1.1. 3.12.11.1.1. The canvas state

Each context maintains a stack of drawing states. Drawing states consist of:

The current path and the current bitmap are not part of the drawing state. The current path is persistent, and can only be reset using the beginPath() method. The current bitmap is a property of the canvas , not the context.

The save() method must push a copy of the current drawing state onto the drawing state stack.

The restore() method must pop the top entry in the drawing state stack, and reset the drawing state it describes. If there is no saved state, the method must do nothing.

3.14.11.1.2. 3.12.11.1.2. Transformations

The transformation matrix is applied to coordinates when creating shapes and paths.

When the context is created, the transformation matrix must initially be the identity transform. It may then be adjusted using the transformation methods.

The transformation matrix can become infinite, at which point nothing is drawn anymore. The transformations must be performed in reverse order. For instance, if a scale transformation that doubles the width is applied, followed by a rotation transformation that rotates drawing operations by a quarter turn, and a rectangle twice as wide as it is tall is then drawn on the canvas, the actual result will be a square.

The scale( x , y ) method must add the scaling transformation described by the arguments to the transformation matrix. The x argument represents the scale factor in the horizontal direction and the y argument represents the scale factor in the vertical direction. The factors are multiples. If either argument is Infinity the transformation matrix must be marked as infinite instead of the method throwing an exception.

The rotate( angle ) method must add the rotation transformation described by the argument to the transformation matrix. The angle argument represents a clockwise rotation angle expressed in radians. If the angle argument is infinite, the method call must be ignored.

The translate( x , y ) method must add the translation transformation described by the arguments to the transformation matrix. The x argument represents the translation distance in the horizontal direction and the y argument represents the translation distance in the vertical direction. The arguments are in coordinate space units. If either argument is Infinity the transformation matrix must be marked as infinite instead of the method throwing an exception.

The transform( m11 , m12 , m21 , m22 , dx , dy ) method must multiply the current transformation matrix with the matrix described by:

m11 m21 dx
m12 m22 dy
0 0 1

If any of the arguments are Infinity the transformation matrix must be marked as infinite instead of the method throwing an exception. The setTransform( m11 , m12 , m21 , m22 , dx , dy ) method must reset the current transform to the identity matrix, and then invoke the transform ( m11 , m12 , m21 , m22 , dx , dy ) method with the same arguments. If any of the arguments are Infinity the transformation matrix must be marked as infinite instead of the method throwing an exception.

3.14.11.1.3. 3.12.11.1.3. Compositing

All drawing operations are affected by the global compositing attributes, globalAlpha and globalCompositeOperation .

The globalAlpha attribute gives an alpha value that is applied to shapes and images before they are composited onto the canvas. The value must be in the range from 0.0 (fully transparent) to 1.0 (no additional transparency). If an attempt is made to set the attribute to a value outside this range, the attribute must retain its previous value. When the context is created, the globalAlpha attribute must initially have the value 1.0.

The globalCompositeOperation attribute sets how shapes and images are drawn onto the existing bitmap, once they have had globalAlpha and the current transformation matrix applied. It must be set to a value from the following list. In the descriptions below, the source image, A , is the shape or image being rendered, and the destination image, B , is the current state of the bitmap.

source-atop
A atop B . Display the source image wherever both images are opaque. Display the destination image wherever the destination image is opaque but the source image is transparent. Display transparency elsewhere.
source-in
A in B . Display the source image wherever both the source image and destination image are opaque. Display transparency elsewhere.
source-out
A out B . Display the source image wherever the source image is opaque and the destination image is transparent. Display transparency elsewhere.
source-over (default)
A over B . Display the source image wherever the source image is opaque. Display the destination image elsewhere.
destination-atop
B atop A . Same as source-atop but using the destination image instead of the source image and vice versa.
destination-in
B in A . Same as source-in but using the destination image instead of the source image and vice versa.
destination-out
B out A . Same as source-out but using the destination image instead of the source image and vice versa.
destination-over
B over A . Same as source-over but using the destination image instead of the source image and vice versa.
lighter
A plus B . Display the sum of the source image and destination image, with color values approaching 1 as a limit.
copy
A ( B is ignored). Display the source image instead of the destination image.
xor
A xor B . Exclusive OR of the source image and destination image.
vendorName - operationName
Vendor-specific extensions to the list of composition operators should use this syntax.

These values are all case-sensitive — they must be used exactly as shown. User agents must only recognise not recognize values that do not exactly match the values given above.

The operators in the above list must be treated as described by the Porter-Duff operator given at the start of their description (e.g. A over B ). [PORTERDUFF]

On setting, if the user agent does not recognise recognize the specified value, it must be ignored, leaving the value of globalCompositeOperation unaffected.

When the context is created, the globalCompositeOperation attribute must initially have the value source-over .

3.14.11.1.4. 3.12.11.1.4. Colors and styles

The strokeStyle attribute represents the color or style to use for the lines around shapes, and the fillStyle attribute represents the color or style to use inside the shapes.

Both attributes can be either strings, CanvasGradient s, or CanvasPattern s. On setting, strings must be parsed as CSS <color> values and the color assigned, and CanvasGradient and CanvasPattern objects must be assigned themselves. [CSS3COLOR] If the value is a string but is not a valid color, or is neither a string, a CanvasGradient , nor a CanvasPattern , then it must be ignored, and the attribute must retain its previous value.

On getting, if the value is a color, then the serialisation serialization of the color must be returned. Otherwise, if it is not a color but a CanvasGradient or CanvasPattern , then the respective object must be returned. (Such objects are opaque and therefore only useful for assigning to other attributes or for comparison to other gradients or patterns.)

The serialisation serialization of a color for a color value is a string, computed as follows: if it has alpha equal to 1.0, then the string is a lowercase six-digit hex value, prefixed with a "#" character (U+0023 NUMBER SIGN), with the first two digits representing the red component, the next two digits representing the green component, and the last two digits representing the blue component, the digits being in the range 0-9 a-f (U+0030 to U+0039 and U+0061 to U+0066). Otherwise, the color value has alpha less than 1.0, and the string is the color value in the CSS rgba() functional-notation format: the literal string rgba (U+0072 U+0067 U+0062 U+0061) followed by a U+0028 LEFT PARENTHESIS, a base-ten integer in the range 0-255 representing the red component (using digits 0-9, U+0030 to U+0039, in the shortest form possible), a literal U+002C COMMA and U+0020 SPACE, an integer for the green component, a comma and a space, an integer for the blue component, another comma and space, a U+0030 DIGIT ZERO, a U+002E FULL STOP (representing the decimal point), one or more digits in the range 0-9 (U+0030 to U+0039) representing the fractional part of the alpha value, and finally a U+0029 RIGHT PARENTHESIS.

When the context is created, the strokeStyle and fillStyle attributes must initially have the string value #000000 .

There are two types of gradients, linear gradients and radial gradients, both represented by objects implementing the opaque CanvasGradient interface.

Once a gradient has been created (see below), stops are placed along it to define how the colors are distributed along the gradient. The color of the gradient at each stop is the color specified for that stop. Between each such stop, the colors and the alpha component must be linearly interpolated over the RGBA space without premultiplying the alpha value to find the color to use at that offset. Before the first stop, the color must be the color of the first stop. After the last stop, the color must be the color of the last stop. When there are no stops, the gradient is transparent black.

The addColorStop( offset , color ) method on the CanvasGradient interface adds a new stop to a gradient. If the offset is less than 0 or 0, greater than 1 1, infinite, or NaN, then an INDEX_SIZE_ERR exception must be raised. If the color cannot be parsed as a CSS color, then a SYNTAX_ERR exception must be raised. Otherwise, the gradient must have a new stop placed, at offset offset relative to the whole gradient, and with the color obtained by parsing color as a CSS <color> value. If multiple stops are added at the same offset on a gradient, they must be placed in the order added, with the first one closest to the start of the gradient, and each subsequent one infinitesimally further along towards the end point (in effect causing all but the first and last stop added at each point to be ignored).

The createLinearGradient( x0 , y0 , x1 , y1 ) method takes four arguments, representing arguments that, after being subjected to the current transformation matrix ,represent the start point ( x0 , y0 ) and end point ( x1 , y1 ) of the gradient, in coordinate space units, and gradient. If any of the arguments to createLinearGradient() are infinite or NaN, the method must raise an INDEX_SIZE_ERR exception. Otherwise, the method must return a linear CanvasGradient initialised initialized with that the specified line.

Linear gradients must be rendered such that at and before the starting point on the canvas the color at offset 0 is used, that at and after the ending point the color at offset 1 is used, and that all points on a line perpendicular to the line that crosses the start and end points have the color at the point where those two lines cross (with the colors coming from the interpolation described above).

If x 0  =  x 1 and y 0  =  y 1 , then the linear gradient must paint nothing.

The createRadialGradient( x0 , y0 , r0 , x1 , y1 , r1 ) method takes six arguments, the first three representing the start circle with origin ( x0 , y0 ) and radius r0 , and the last three representing the end circle with origin ( x1 , y1 ) and radius r1 . The values are in coordinate space units. The method must return a radial CanvasGradient initialised with those two circles. If either of r0 or r1 are negative, or if any of the arguments are infinite or NaN, an INDEX_SIZE_ERR exception must be raised. Otherwise, the method must return a radial CanvasGradient initialized with the two specified circles, after transforming them according to the current transformation matrix .

Radial gradients must be rendered by following these steps:

  1. If x 0  =  x 1 and y 0  =  y 1 and r 0  =  r 1 ,then the radial gradient must paint nothing. Abort these steps.

  2. Let x( ω ) = ( x 1 - x 0 ) ω  +  x 0

    Let y( ω ) = ( y 1 - y 0 ) ω  +  y 0

    Let r( ω ) = ( r 1 - r 0 ) ω  +  r 0

    Let the color at ω be the color of the gradient at offset 0.0 for all values of ω less than 0.0, the color at offset 1.0 for all values of ω greater than 1.0, and the color at the given offset for values of ω in the range 0.0 ≤  ω  ≤ 1.0

  3. For all values of ω where r( ω ) > 0 , starting with the value of ω nearest to positive infinity and ending with the value of ω nearest to negative infinity, draw the circumference of the circle with radius r( ω ) at position ( x( ω ) , y( ω ) ), with the color at ω , but only painting on the parts of the canvas that have not yet been painted on by earlier circles in this step for this rendering of the gradient.

If x 0  =  x 1 and y 0  =  y 1 and r 0  =  r 1 , then the radial gradient must paint nothing.

This effectively creates a cone, touched by the two circles defined in the creation of the gradient, with the part of the cone before the start circle (0.0) using the color of the first offset, the part of the cone after the end circle (1.0) using the color of the last offset, and areas outside the cone untouched by the gradient (transparent black).

Gradients must only be painted only where the relevant stroking or filling effects requires that they be drawn. Support for actually painting gradients is optional. Instead of painting the gradients, user agents may instead just paint the first stop's color. However, createLinearGradient() and createRadialGradient() must always return objects when passed valid arguments.

Patterns are represented by objects implementing the opaque CanvasPattern interface.

To create objects of this type, the createPattern(image, repetition) createPattern( image ,repetition ) method is used. The first argument gives the image to use as the pattern (either an HTMLImageElement or an HTMLCanvasElement ). Modifying this image after calling the createPattern() method must not affect the pattern. The second argument must be a string with one of the following values: repeat , repeat-x , repeat-y , no-repeat . If the empty string or null is specified, repeat must be assumed. If an unrecognised unrecognized value is given, then the user agent must raise a SYNTAX_ERR exception. User agents must recognise recognize the four values described above exactly (e.g. they must not do case folding). The method must return a CanvasPattern object suitably initialised. initialized.

The image argument must be an instance of an HTMLImageElement or HTMLCanvasElement . If the image is of the wrong type, type or null, the implementation must raise a TYPE_MISMATCH_ERR exception.

If the image argument is an HTMLImageElement object whose complete attribute is false, then the implementation must raise an INVALID_STATE_ERR exception.

If the image argument is an HTMLCanvasElement object with either a horizontal dimension or a vertical dimension equal to zero, then the implementation must raise an INVALID_STATE_ERR exception.

Patterns must be painted so that the top left of the first image is anchored at the origin of the coordinate space, and images are then repeated horizontally to the left and right (if the repeat-x string was specified) or vertically up and down (if the repeat-y string was specified) or in all four directions all over the canvas (if the repeat string was specified). The images are not be scaled by this process; one CSS pixel of the image must be painted on one coordinate space unit. Of course, patterns must only actually be painted only where the stroking or filling effect requires that they be drawn, and are affected by the current transformation matrix.

When the createPattern() method is passed, as its image argument, an animated image, the poster frame of the animation, or the first frame of the animation if there is no poster frame, must be used.

Support for patterns is optional. If the user agent doesn't support patterns, then createPattern() must return null.

3.14.11.1.5. 3.12.11.1.5. Line styles

The lineWidth attribute gives the default width of lines, in coordinate space units. On setting, zero zero, negative, infinite, and negative NaN values must be ignored, leaving the value unchanged.

When the context is created, the lineWidth attribute must initially have the value 1.0 .

The lineCap attribute defines the type of endings that UAs shall will place on the end of lines. The three valid values are butt , round , and square . The butt value means that the end of each line is a flat edge perpendicular to the direction of the line. The round value means that a semi-circle with the diameter equal to the width of the line is must then be added on to the end of the line. The square value means that at the end of each line is a rectangle with the length of the line width and the width of half the line width, placed flat against the edge perpendicular to the direction of the line, must be added at the end of each line. On setting, any other value than the literal strings butt , round , and square must be ignored, leaving the value unchanged.

When the context is created, the lineCap attribute must initially have the value butt .

The lineJoin attribute defines the type of corners that that UAs will place where two lines meet. The three valid values are round bevel , bevel round , and miter .

On setting, any other value than the literal strings round bevel , bevel round , and miter must be ignored, leaving the value unchanged.

When the context is created, the lineJoin attribute must initially have the value miter .

The round value means that A join exists at any point in a filled arc subpath shared by two consecutive lines. When a subpath is closed, then a join also exists at its first point (equivalent to its last point) connecting the corners on first and last lines in the outside of subpath.

In addition to the join, with point where the diameter equal join occurs, two additional points are relevant to each join, one for each line: the two corners found half the line width, and width away from the origin at join point, one perpendicular to each line, each on the point where side furthest from the inside edges other line.

A filled triangle connecting these two opposite corners with a straight line, with the third point of the lines touch, triangle being the join point, must be rendered at all joins. The lineJoin attribute controls whether anything else is rendered. The three aforementioned values have the following meanings:

The bevel value means that this is all that is rendered at joins.

The round value means that a filled triangle arc connecting those the two aforementioned corners with a straight line, the third point of the triangle being join, abutting (and not overlapping) the point where aforementioned triangle, with the lines touch on diameter equal to the inside line width and the origin at the point of the join, must be rendered at joins.

The miter value means that a second filled four- or five-sided polygon triangle must (if it can given the miter length) be placed rendered at the join, with two of the lines one line being the perpendicular edges of line between the joining lines, two aforementioned corners, abutting the first triangle, and the other two being continuations of the outside edges of the two joining lines, as long as required to intersect without going over the miter limit. length.

The miter length is the distance from the point where the lines touch on the inside of the join to the intersection of the line edges on the outside of the join. The miter limit ratio is the maximum allowed ratio of the miter length of the two continuation lines to the line width. If the miter limit length would be exceeded, then a fifth line this second triangle must not be added to the polygon, connecting the two outside lines, such that the distance from the inside point of the join to the point in the middle of this fifth line is the maximum allowed value for the miter length. rendered.

The miter limit ratio can be explicitly set using the miterLimit attribute. On setting, zero zero, negative, infinite, and negative NaN values must be ignored, leaving the value unchanged.

When the context is created, the miterLimit attribute must initially have the value 10.0 .

3.14.11.1.6. 3.12.11.1.6. Shadows

All drawing operations are affected by the four global shadow attributes.

The shadowColor attribute sets the color of the shadow.

When the context is created, the shadowColor attribute initially must be fully-transparent black.

On getting, the serialisation serialization of the color must be returned.

On setting, the new value must be parsed as a CSS <color> value and the color assigned. If the value is not a valid color, then it must be ignored, and the attribute must retain its previous value. [CSS3COLOR]

The shadowOffsetX and shadowOffsetY attributes specify the distance that the shadow will be offset in the positive horizontal and positive vertical distance respectively. Their values are in coordinate space units. They are not affected by the current transformation matrix.

When the context is created, the shadow offset attributes initially have the value 0 .

On getting, they must return their current value. On setting, the attribute being set must be set to the new value. value, except if the value is infinite or NaN, in which case the new value must be ignored.

The shadowBlur attribute specifies the size of the blurring effect. (The units do not map to coordinate space units, and are not affected by the current transformation matrix.)

When the context is created, the shadowBlur attribute must initially have the value 0 .

On getting, the attribute must return its current value. On setting, if the value is greater than or equal to zero, then setting the attribute must be set to the new value; otherwise, value, except if the new value is negative, infinite or NaN, in which case the new value must be ignored.

Support for shadows is optional. When they are supported, then, when shadows are drawn, they must be rendered as follows:

  1. Let A be the source image for which a shadow is being created.

  2. Let B be an infinite transparent black bitmap, with a coordinate space and an origin identical to A .

  3. Copy the alpha channel of A to B , offset by shadowOffsetX in the positive x direction, and shadowOffsetY in the positive y direction.

  4. If shadowBlur is greater than 0:

    1. If shadowBlur is less than 8, let σ be half the value of shadowBlur ; otherwise, let σ be the square root of multiplying the value of shadowBlur by 2.

    2. Perform a 2D Gaussian Blur on B , using σ as the standard deviation.

    User agents may limit values of σ to an implementation-specific maximum value to avoid exceeding hardware limitations during the Gaussian blur operation.

  5. Set the red, green, and blue components of every pixel in B to the red, green, and blue components (respectively) of the color of shadowColor .

  6. Multiply the alpha component of every pixel in B by the alpha component of the color of shadowColor .

  7. The shadow is in the bitmap B , and is rendered as part of the drawing model described below.

3.14.11.1.7. 3.12.11.1.7. Simple shapes (rectangles)

There are three methods that immediately draw rectangles to the bitmap. They each take four arguments; the first two give the x and y coordinates of the top left of the rectangle, and the second two give the width w and height h of the rectangle, respectively.

The current transformation matrix must be applied to the following four coordinates, which form the path that must then be closed to get the specified rectangle: ( x , y ) , ( x + w , y ) , ( x + w , y + h ) , ( x , y + h ) .

Shapes are painted without affecting the current path, and are subject to the clipping paths region , and, with the exception of clearRect() , also shadow effects , global alpha , and global composition operators .

Negative values for width and height must cause the implementation to raise an INDEX_SIZE_ERR exception. The clearRect() clearRect( x ,y ,w ,h ) method must clear the pixels in the specified rectangle that also intersect the current clipping path region to a fully transparent black, erasing any previous image. If either height or width are zero, this method has no effect.

The fillRect() fillRect( x ,y ,w ,h ) method must paint the specified rectangular area using the fillStyle . If either height or width are zero, this method has no effect.

The strokeRect() strokeRect( x ,y ,w ,h ) method must stroke the specified rectangle's path using the strokeStyle , lineWidth , lineJoin , and (if appropriate) miterLimit attributes. If both height and width are zero, this method has no effect, since there is no path to stroke (it's a point). If only one of the two is zero, then the method will draw a line instead (the path for the outline is just a straight line along the non-zero dimension).

3.14.11.1.8. 3.12.11.1.8. Complex shapes (paths)

The context always has a current path. There is only one current path, it is not part of the drawing state .

A path has a list of zero or more subpaths. Each subpath consists of a list of one or more points, connected by straight or curved lines, and a flag indicating whether the subpath is closed or not. A closed subpath is one where the last point of the subpath is connected to the first point of the subpath by a straight line. Subpaths with fewer than two points are ignored when painting the path.

Initially, the context's path must have zero subpaths.

The coordinates given in the arguments points and lines added to the path by these methods must be transformed according to the current transformation matrix before applying the calculations described below and before adding any points to the path. as they are added.

The beginPath() method must empty the list of subpaths so that the context once again has zero subpaths.

The moveTo( x , y ) method must create a new subpath with the specified point as its first (and only) point.

The closePath() method must do nothing if the context has no subpaths. Otherwise, it must mark the last subpath as closed, create a new subpath whose first point is the same as the previous subpath's first point, and finally add this new subpath to the path. (If the last subpath had more than one point in its list of points, then this is equivalent to adding a straight line connecting the last point back to the first point, thus "closing" the shape, and then repeating the last moveTo() call.)

New points and the lines connecting them are added to subpaths using the methods described below. In all cases, the methods only modify the last subpath in the context's paths.

The lineTo( x , y ) method must do nothing if the context has no subpaths. Otherwise, it must connect the last point in the subpath to the given point ( x , y ) using a straight line, and must then add the given point ( x , y ) to the subpath.

The quadraticCurveTo( cpx , cpy , x , y ) method must do nothing if the context has no subpaths. Otherwise it must connect the last point in the subpath to the given point ( x , y ) using a quadratic Bézier curve with control point ( cpx , cpy ), and must then add the given point ( x , y ) to the subpath. [BEZIER]

The bezierCurveTo( cp1x , cp1y , cp2x , cp2y , x , y ) method must do nothing if the context has no subpaths. Otherwise, it must connect the last point in the subpath to the given point ( x , y ) using a cubic Bézier curve with control points ( cp1x , cp1y ) and ( cp2x , cp2y ). Then, it must add the point ( x , y ) to the subpath. [BEZIER]

The arcTo( x1 , y1 , x2 , y2 , radius ) method must do nothing if the context has no subpaths. If the context does have a subpath, then the behaviour behavior depends on the arguments and the last point in the subpath.

Negative values for radius must cause the implementation to raise an INDEX_SIZE_ERR exception.

Let the point ( x0 , y0 ) be the last point in the subpath. Let

If the point ( The Arc x0 ,y0 be ) is equal to the shortest arc given by circumference of point ( x1 ,y1 ), or if the circle point ( x1 ,y1 ) is equal to the point ( x2 ,y2 ), then the method must add the point ( x1 ,y1 ) to the subpath, and connect that has one point tangent to the line defined previous point ( x0 ,y0 ) by a straight line.

Otherwise, if the points ( x0 , y0 ) ), ( x1 ,y1 ), and ( x2 ,y2 ) all lie on a single straight line, then: if the direction from ( x0 ,y0 ) to ( x1 , y1 ) is the same as the direction from ( x1 ,y1 ) to ( x2 ,y2 ), another then method must add the point tangent ( x1 ,y1 ) to the line defined subpath, and connect that point to the previous point ( x0 ,y0 ) by a straight line; otherwise, the points direction from ( x0 ,y0 ) to ( x1 , y1 ) and is the opposite of the direction from ( x1 ,y1 ) to ( x2 , y2 ), and that has radius the method must add a point ( radius . The points at which this circle touches these two lines are called x ,y ) to the start subpath, and end tangent points respectively. If connect that point to the previous point ( x0 ,y0 ) by a straight line, where ( x ,y ) is the point that is infinitely far away from ( x1 ,y1 ), that lies on the same line as ( x0 ,y0 ), ( x1 ,y1 ), and ( x2 , y2 ) ), and that is on the same side of ( x1 ,y1 ) on that line defined as ( x2 ,y2 ).

Otherwise, let The Arc be the shortest arc given by circumference of the points circle that has radius radius ,and that has one point tangent to the half-infinite line that crosses the point ( x0 , y0 ) and ends at the point ( x1 ,y1 ), and that has a different point tangent to the half-infinite line that ends at the point ( x1 , y1 ) then and crosses the method must do nothing, as no arc would satisfy point ( x2 ,y2 ). The points at which this circle touches these two lines are called the above constraints. start and end tangent points respectively.

Otherwise, the The method must connect the point ( x0 , y0 ) to the start tangent point by a straight line, adding the start tangent point to the subpath, and then must connect the start tangent point to the end tangent point by The Arc , and finally add adding the start and end tangent points point to the subpath.

Negative or zero values for radius must cause the implementation to raise an INDEX_SIZE_ERR exception. The arc( x , y , radius , startAngle , endAngle , anticlockwise ) method draws an arc. If the context has any subpaths, then the method must add a straight line from the last point in the subpath to the start point of the arc. In any case, it must draw the arc between the start point of the arc and the end point of the arc, and add the start and end points of the arc to the subpath. The arc and its start and end points are defined as follows:

Consider a circle that has its origin at ( x , y ) and that has radius radius . The points at startAngle and endAngle along the circle's circumference, measured in radians clockwise from the positive x-axis, are the start and end points respectively. The arc is the path along the circumference of this circle from the start point to the end point, going anti-clockwise if the anticlockwise argument is true, and clockwise otherwise. Negative Since the points are on the circle, as opposed to being simply angles from zero, the arc can never cover an angle greater than 2π radians. If the two angles are equal, or if the radius is zero, then the arc is defined as being of zero length in both directions.

Negative values for radius must cause the implementation to raise an INDEX_SIZE_ERR exception.

The rect( x , y , w , h ) method must create a new subpath containing just the four points ( x , y ), ( x + w , y ), ( x + w , y + h ), ( x , y + h ), with those four points connected by straight lines, and must then mark the subpath as closed. It must then create a new subpath with the point ( x , y ) as the only point in the subpath.

Negative values for w and h must cause the implementation to raise an INDEX_SIZE_ERR exception. The fill() method must fill each subpath all the subpaths of the current path in turn, path, using fillStyle , and using the non-zero winding number rule. Open subpaths must be implicitly closed when being filled (without affecting the actual subpaths).

Thus, if two overlapping but otherwise independent subpaths have opposite windings, they cancel out and result in no fill. If they have the same winding, that area just gets painted once.

The stroke() method must stroke each subpath calculate the strokes of all the subpaths of the current path in turn, path, using the strokeStyle lineWidth , lineWidth lineCap , lineJoin , and (if appropriate) miterLimit attributes. attributes, and then fill the combined stroke area using the strokeStyle ,attribute.

Since the subpaths are all stroked as one, overlapping parts of the paths in one stroke operation are treated as if their union was what was painted.

Paths, when filled or stroked, must be painted without affecting the current path, and must be subject to transformations , shadow effects , global alpha , the clipping paths region , and global composition operators . The transformation is applied to (Transformations affect the path when it the path is drawn, created, not when it is painted, though the path stroke style is constructed. Thus, a single path can be constructed and then drawn according to different transformations without recreating still affected by the transformation during painting.)

Zero-length line segments must be pruned before stroking a path. Empty subpaths must be ignored.

The clip() method must create a new clipping path region by calculating the intersection of the current clipping path region and the area described by the current path, using the non-zero winding number rule. Open subpaths must be implicitly closed when computing the clipping path, region, without affecting the actual subpaths. The new clipping region replaces the current clipping region.

When the context is created, initialized, the initial clipping path is region must be set to the rectangle with the top left corner at (0,0) and the width and height of the coordinate space.

The isPointInPath( x , y ) method must return true if the point given by the x and y coordinates passed to the method, when treated as coordinates in the canvas' canvas coordinate space unaffected by the current transformation, is within inside the area current path; and must return false otherwise. Points on the path itself are considered to be inside the path. If either of the arguments is infinite or NaN, then the method must return false.

3.12.11.1.9. Text

The font DOM attribute, on setting, must be parsed the same way as the 'font' property of CSS (but without supporting property-independent stylesheet syntax like 'inherit'), and the resulting font must be assigned to the context, with the 'line-height' component forced to 'normal'. [CSS]

Font names must be interpreted in the context of the canvas that element's stylesheets; any fonts embedded using @font-face must therefore be available. [CSSWEBFONTS]

Only vector fonts should be used by the user agent; if a user agent were to use bitmap fonts then transformations would likely make the font look very ugly.

On getting, the font attribute must return the serialized form of the current font of the context. [CSSOM]

When the context is created, the font of the context must be filled set to 10px sans-serif. When the 'font-size' component is set to lengths using percentages, 'em' or 'ex' units, or the 'larger' or 'smaller' keywords, these must be interpreted relative to the computed value of the 'font-size' property of the corresponding canvas element. When the 'font-weight' component is set to the relative values 'bolder' and 'lighter', these must be interpreted relative to the computed value of the 'font-weight' property of the corresponding canvas element.

The textAlign DOM attribute, on getting, must return the current value. On setting, if the value is one of start ,end ,left ,right ,or center ,then the value must be changed to the new value. Otherwise, the new value must be ignored. When the context is created, the textAlign attribute must initially have the value start .

The textBaseline DOM attribute, on getting, must return the current path value. On setting, if the value is one of top ,hanging ,middle ,alphabetic ,ideographic ,or bottom ,then the value must be changed to the new value. Otherwise, the new value must be ignored. When the context is created, the textBaseline attribute must initially have the value alphabetic .

The textBaseline attribute's allowed keywords correspond to alignment points in the font:

The top of the em square is roughly at the top of the glyphs in a font, the hanging baseline is where some glyphs like आ are anchored, the middle is half-way between the top of the em square and the bottom of the em square, the alphabetic baseline is where characters like Á, ÿ, f, and Ω are anchored, the ideographic baseline is where glyphs like 私 and 達 are anchored, and the bottom of the em square is roughly at the bottom of the glyphs in a font. The top and bottom of the bounding box can be far from these baselines, due to glyphs extending far outside the em square.

The keywords map to these alignment points as follows:

top
The top of the em square
hanging
The hanging baseline
middle
The middle of the em square
alphabetic
The alphabetic baseline
ideographic
The ideographic baseline
bottom
The bottom of the em square

The fillText() and strokeText() methods take three or four arguments, text ,x ,y ,and optionally maxWidth ,and render the given text at the given ( x ,y ) coordinates ensuring that the text isn't wider than maxWidth if specified, using the current font ,textAlign ,and textBaseline values. Specifically, when the methods are called, the user agent must run the following steps:

  1. Let font be the current font of the browsing context, as given by the font attribute.

  2. Replace all the space characters in text with U+0020 SPACE characters.

  3. Form a hypothetical infinitely wide CSS line box containing a single inline box containing the text text ,with all the properties at their initial values except the 'font' property of the inline element set to font and the 'direction' property of the inline element set to the 'direction' property of the canvas element. [CSS]

  4. If the maxWidth argument was specified and the hypothetical width of the inline box in the hypothetical line box is greater than maxWidth CSS pixels, then change font to have a more condensed font (if one is available or if a reasonably readable one can be filled; synthesized by applying a horizontal scale factor to the font) or a smaller font, and return to the previous step.

  5. Let the anchor point be a point on the inline box, determined by the textAlign and textBaseline values, as follows:

    Horizontal position:

    If textAlign is left
    If textAlign is start and the 'direction' property on the canvas element has a computed value of 'ltr'
    If textAlign is end and the 'direction' property on the canvas element has a computed value of 'rtl'
    Let the anchor point 's horizontal position be the left edge of the inline box.
    If textAlign is right
    If textAlign is end and the 'direction' property on the canvas element has a computed value of 'ltr'
    If textAlign is start and the 'direction' property on the canvas element has a computed value of 'rtl'
    Let the anchor point 's horizontal position be the right edge of the inline box.
    If textAlign is center
    Let the anchor point 's horizontal position be half way between the left and right edges of the inline box.

    Vertical position:

    If textBaseline is top
    Let the anchor point 's vertical position be the top of the em box of the first available font of the inline box.
    If textBaseline is hanging
    Let the anchor point 's vertical position be the hanging baseline of the first available font of the inline box.
    If textBaseline is middle
    Let the anchor point 's vertical position be half way between the bottom and the top of the em box of the first available font of the inline box.
    If textBaseline is alphabetic
    Let the anchor point 's vertical position be the alphabetic baseline of the first available font of the inline box.
    If textBaseline is ideographic
    Let the anchor point 's vertical position be the ideographic baseline of the first available font of the inline box.
    If textBaseline is bottom
    Let the anchor point 's vertical position be the bottom of the em box of the first available font of the inline box.
  6. Paint the hypothetical inline box as the shape given by the text's glyphs, as transformed by the current transformation matrix ,and anchored and sized so that before applying the current transformation matrix ,the anchor point is at ( x ,y ) and each CSS pixel is mapped to one coordinate space unit.

    For fillText() fillStyle must be applied to the glyphs and strokeStyle must be ignored. For strokeText() the reverse holds and strokeStyle must be applied to the glyph outlines and fillStyle must be ignored.

    Text is painted without affecting the current path, and is subject to shadow effects ,global alpha ,the clipping region ,and global composition operators .

The measureText() method takes one argument, text .When the method is invoked, the user agent must replace all the space characters in text with U+0020 SPACE characters, and then must form a hypothetical infinitely wide CSS line box containing a single inline box containing the text text ,with all the properties at their initial values except the 'font' property of the inline element set to the current font of the browsing context, as given by the font attribute, and must then return false otherwise. a new TextMetrics object with its width attribute set to the width of that inline box, in CSS pixels. [CSS]

The TextMetrics interface is used for the objects returned from measureText() .It has one attribute, width ,which is set by the measureText() method.

Glyphs rendered using fillText() and strokeText() can spill out of the box given by the font size (the em square size) and the width returned by measureText() (the text width). This version of the specification does not provide a way to obtain the bounding box dimensions of the text. If the text is to be rendered and removed, care needs to be taken to replace the entire area of the canvas that the clipping region covers, not just the box given by the em square height and measured text width.

A future version of the 2D context API may provide a way to render fragments of documents, rendered using CSS, straight to the canvas. This would be provided in preference to a dedicated way of doing multiline layout.

3.14.11.1.9. 3.12.11.1.10. Images

To draw images onto the canvas, the drawImage method can be used.

This method is overloaded with three variants: drawImage( image , dx , dy ) , drawImage( image , dx , dy , dw , dh ) , and drawImage( image , sx , sy , sw , sh , dx , dy , dw , dh ) . (Actually it is overloaded with six; each of those three can take either an HTMLImageElement or an HTMLCanvasElement for the image argument.) If not specified, the dw and dh arguments must default to the values of sw and sh , interpreted such that one CSS pixel in the image is treated as one unit in the canvas coordinate space. If the sx , sy , sw , and sh arguments are omitted, they must default to 0, 0, the image's intrinsic width in image pixels, and the image's intrinsic height in image pixels, respectively.

The image argument must be an instance of an HTMLImageElement or HTMLCanvasElement . If the image is of the wrong type, type or null, the implementation must raise a TYPE_MISMATCH_ERR exception.

If one of the sy image argument is an HTMLImageElement object whose complete attribute is false, then the implementation must raise an INVALID_STATE_ERR exception.

The source rectangle is the rectangle whose corners are the four points ( sx , sy ), ( sx + sw , , sy ), ( sx + sw , sy + sh ), ( sx , and sy + sh arguments is outside ).

If the size of source rectangle is not entirely within the source image, or if one of the dw sw and or dh sh arguments is negative, zero, the implementation must raise an INDEX_SIZE_ERR exception. If

The destination rectangle is the rectangle whose corners are the four points ( image dx ,dy argument is an ), ( HTMLImageElement dx + dw object whose complete attribute is false, then the implementation must raise an INVALID_STATE_ERR exception. , dy ), ( dx + dw ,dy + dh ), ( dx ,dy + dh ).

When drawImage() is invoked, the specified region of the image specified by the source rectangle ( sx , sy , sw , sh ) must be painted on the region of the canvas specified by the destination rectangle ( dx , dy , dw , dh ), rectangle, after applying the current transformation matrix . to the points of the destination rectangle.

When a canvas is drawn onto itself, the drawing model requires the source to be copied before the image is drawn back onto the canvas, so it is possible to copy parts of a canvas onto overlapping parts of itself.

When the drawImage() method is passed, as its image argument, an animated image, the poster frame of the animation, or the first frame of the animation if there is no poster frame, must be used.

Images are painted without affecting the current path, and are subject to shadow effects , global alpha , the clipping paths region , and global composition operators .

3.14.11.1.10. 3.12.11.1.11. Pixel manipulation

The createImageData( sw ,sh ) method must return an ImageData object representing a rectangle with a width in CSS pixels equal to the absolute magnitude of sw and a height in CSS pixels equal to the absolute magnitude of sh ,filled with transparent black.

The getImageData( sx , sy , sw , sh ) method must return an ImageData object representing the underlying pixel data for the area of the canvas denoted by the rectangle which has its top left corner at whose corners are the four points ( sx , sy ) coordinate, and that has width ), ( sx + sw and height , sy ), ( sx + sw ,sy + sh . ), ( sx ,sy + sh ), in canvas coordinate space units. Pixels outside the canvas must be returned as transparent black. Pixels must be returned as non-premultiplied alpha values.

If any of the arguments to createImageData() or getImageData() are infinite or NaN, or if either the sw or sh arguments are zero, the method must instead raise an INDEX_SIZE_ERR exception.

ImageData objects must be initialised initialized so that their width attribute is set to w , the number of physical device pixels per row in the image data, their height attribute is set to h , the number of rows in the image data, and the data attribute is initialised initialized to an array of h × w ×4 integers. The pixels must be represented in this array in left-to-right order, row by row, starting at the top left, with each pixel's red, green, blue, and alpha components being given in that order. Each component of each device pixel represented in this array must be in the range 0..255, representing the 8 bit value for that component. At least one pixel must be returned.

The values of the data array may be changed (the length of the array, and the other attributes in ImageData objects, are all read-only). On setting, JS undefined values must be converted to zero. Other values must first be converted to numbers using JavaScript's ToNumber algorithm, and if the result is not a number, NaN value, a TYPE_MISMATCH_ERR exception must be raised. If the result is less than 0, it must be clamped to zero. If the result is more than 255, it must be clamped to 255. If the number is not an integer, it must be rounded to the nearest integer using the IEEE 754r roundTiesToEven rounding mode. [ECMA262] [IEEE754R]

The width and height ( w and h ) might be different from the sw and sh arguments to the function, above methods, e.g. if the canvas is backed by a high-resolution bitmap. If the getImageData( sx , sy , sw , sh ) method is called with either bitmap, or if the sw or and sh arguments set to zero or negative values, the method must raise an INDEX_SIZE_ERR exception. are negative.

The putImageData( imagedata , dx , dy , dirtyX ,dirtyY ,dirtyWidth ,dirtyHeight ) method must take the given writes data from ImageData structure, and place it at the specified location ( dx , dy ) in the canvas coordinate space, mapping each pixel represented by structures back to the ImageData structure into one device pixel. canvas.

If the first argument to the method is null or not an object whose [[Class]] property is ImageData , but all of the following conditions are true, object that was returned by createImageData() or getImageData() then the method must treat the first argument as if it was an ImageData putImageData() object (and thus not method must raise the a TYPE_MISMATCH_ERR exception): The method's first argument is exception.

If any of the arguments to the method are infinite or NaN, the method must raise an object with INDEX_SIZE_ERR exception.

When the last four arguments are omitted, they must be assumed to have the values 0, 0, the width member of the imagedata structure, and the height attributes member of the imagedata structure, respectively.

When invoked with integer values and a arguments that do not, per the last few paragraphs, cause an exception to be raised, the data putImageData() attribute whose value method must act as follows:

  1. Let dx device be the x-coordinate of the device pixel in the underlying pixel data of the canvas corresponding to the dx coordinate in the canvas coordinate space.

    Let dy device be the y-coordinate of the device pixel in the underlying pixel data of the canvas corresponding to the dy coordinate in the canvas coordinate space.

  2. If dirtyWidth is an enumerable list negative, let dirtyX be dirtyX + dirtyWidth ,and let dirtyWidth be equal to the absolute magnitude of values that are either JS Numbers or dirtyWidth .

    If dirtyHeight is negative, let dirtyY be dirtyY + dirtyHeight ,and let dirtyHeight be equal to the JS value undefined . absolute magnitude of dirtyHeight .

  3. The

    If dirtyX is negative, let dirtyWidth be ImageData dirtyWidth + dirtyX ,and let dirtyX be zero.

    If dirtyY is negative, let dirtyHeight be dirtyHeight + dirtyY ,and let dirtyY be zero.

  4. If dirtyX + dirtyWidth is greater than the width object's attribute of the imagedata argument, let dirtyWidth be the value of that width attribute, minus the value of dirtyX .

    If dirtyY + dirtyHeight is greater than zero. The the ImageData height object's attribute of the imagedata argument, let dirtyHeight be the value of that height attribute, minus the value of dirtyY .

  5. If, after those changes, either dirtyWidth or dirtyHeight is greater than zero. negative or zero, stop these steps without affecting the canvas.

  6. The

    Otherwise, for all values of x and y where ImageData dirtyX  ≤  x  <  object's dirtyX + dirtyWidth width multiplied by its and height dirtyY  ≤  y  <  multiplied by 4 is equal to dirtyY + dirtyHeight ,copy the number four channels of entries the pixel with coordinate ( x ,y ) in the imagedata data structure to the pixel with coordinate ( ImageData x device object's + x data , property. In the y device data + y property, undefined values must be treated as zero, any numbers below zero must be clamped to zero, any numbers above 255 must be clamped to 255, and any numbers that are not integers must be rounded to ) in the nearest integer using underlying pixel data of the IEEE 754r roundTiesToEven rounding mode. [IEEE754R] canvas.

The handling of pixel rounding when the specified coordinates do not exactly map to the device coordinate space is not defined by this specification, except that the following must result in no visible changes to the rendering:

context.putImageData(context.getImageData(x,
y,
w,
h),
x,
y);

...for any value of x and y . In other words, while user agents may round the arguments of the two methods so that they map to device pixel boundaries, any rounding performed must be performed consistently for both the getImageData() and putImageData() operations.

The current path, transformation matrix , shadow attributes , global alpha , the clipping path region , and global composition operator must not affect the getImageData() and putImageData() methods.

The data returned by getImageData() is at the resolution of the canvas backing store, which is likely to not be one device pixel to each CSS pixel if the display used is a high resolution display. Thus, while one could create an ImageData object, one would not necessarily know what resolution the canvas expected (how many pixels the canvas wants to paint over one coordinate space unit pixel).

In the following example, the script first obtains the size of the canvas backing store, and then generates a few new ImageData objects which can be used.

  // canvas is a reference to a <canvas> element
  // (note: this example uses JavaScript 1.7 features)

  var context = canvas.getContext('2d');
  var backingStore = context.getImageData(0, 0, canvas.width, canvas.height);
  var actualWidth = backingStore.width;
  var actualHeight = backingStore.height;
  function CreateImageData(w, h) {
    return {
      height: h,
      width: w,
      data: [i for (i in function (n) { for (let i = 0; i < n; i += 1) yield 0 }(w*h*4)) ]
    };
  }

  // create a blank slate
  var data = CreateImageData(actualWidth, actualHeight);

  var data = context.createImageData(canvas.width, canvas.height);

  // create some plasma
  FillPlasma(data, 'green'); // green plasma
  // add a cloud to the plasma
  AddCloud(data, actualWidth/2, actualHeight/2); // put a cloud in the middle

  AddCloud(data, data.width/2, data.height/2); // put a cloud in the middle

  // paint the plasma+cloud on the canvas
  context.putImageData(data, 0, 0);
  // support methods
  function FillPlasma(data, color) { ... }
  function AddCload(data, x, y) { ... }

  function AddCloud(data, x, y) { ... }

Here is an example of using getImageData() and putImageData() to implement an edge detection filter.

<!DOCTYPE HTML>
<html>
 <head>
  <title>Edge detection demo</title>
  <script>
   var image = new Image();
   function init() {
     image.onload = demo;
     image.src = "image.jpeg";
   }
   function demo() {
     var canvas = document.getElementsByTagName('canvas')[0];
     var context = canvas.getContext('2d');
     // draw the image onto the canvas
     context.drawImage(image, 0, 0);
     // get the image data to manipulate
     var input = context.getImageData(0, 0, canvas.width, canvas.height);
     // edge detection

     // get an empty slate to put the data into
     var output = context.crateImageData(canvas.width, canvas.height);
     // alias some variables for convenience

     // notice that we are using input.width and input.height here
     // as they might not be the same as canvas.width and canvas.height
     // (in particular, they might be different on high-res displays)
     var w = input.width, h = input.height;
     var inputData = input.data;
     var outputData = new Array(w*h*4);

     var outputData = output.data;
     // edge detection

     for (var y = 1; y < h-1; y += 1) {
       for (var x = 1; x < w-1; x += 1) {
         for (var c = 0; c < 3; c += 1) {
           var i = (y*w + x)*4 + c;
           outputData[i] = 127 + -inputData[i - w*4 - 4] -   inputData[i - w*4] - inputData[i - w*4 + 4] +
                                 -inputData[i - 4]       + 8*inputData[i]       - inputData[i + 4] +
                                 -inputData[i + w*4 - 4] -   inputData[i + w*4] - inputData[i + w*4 + 4];
         }
         outputData[(y*w + x)*4 + 3] = 255; // alpha
       }
     }
     // put the image data back after manipulation
     var output = {
       width: w,
       height: h,
       data: outputData
     };

     context.putImageData(output, 0, 0);
   }
  </script>
 </head>
 <body onload="init()">
  <canvas></canvas>
 </body>
</html>
3.14.11.1.11. 3.12.11.1.12. Drawing model

When a shape or image is painted, user agents must follow these steps, in the order given (or act as if they do):

  1. Render the shape or image, creating image A , as described in the previous sections. For shapes, the current fill, stroke, and line styles must be honoured, honored, and the stroke must itself also be subjected to the current transformation matrix.

  2. If shadows are supported:

    1. Render the shadow from image A , using the current shadow styles, creating image B .

    2. Multiply the alpha component of every pixel in B by globalAlpha .

    3. Within the clipping path, region, composite B over the current canvas bitmap using the current composition operator.

  3. Multiply the alpha component of every pixel in A by globalAlpha .

  4. Within the clipping path, region, composite A over the current canvas bitmap using the current composition operator.

3.14.11.2. 3.12.11.2. Color spaces and color correction

The canvas APIs must perform colour color correction at only two points: when rendering images with their own gamma correction and color space information onto the canvas, to convert the image to the color space used by the canvas (e.g. using the drawImage() method with an HTMLImageElement object), and when rendering the actual canvas bitmap to the output device.

Thus, in the 2D context, colors used to draw shapes onto the canvas will exactly match colors obtained through the getImageData() method.

The toDataURL() method must not include color space information in the resource returned. Where the output format allows it, the color of pixels in resources created by toDataURL() must match those returned by the getImageData() method.

In user agents that support CSS, the color space used by a canvas element must match the color space used for processing any colors for that element in CSS.

The gamma correction and color space information of images must be handled in such a way that an image rendered directly using an img element would use the same colors as one painted on a canvas element that is then itself rendered. Furthermore, the rendering of images that have no color correction information (such as those returned by the toDataURL() method) must be rendered with no color correction.

Thus, in the 2D context, calling the drawImage() method to render the output of the toDataURL() method to the canvas, given the appropriate dimensions, has no visible effect.

3.12.11.3. Security with canvas elements

Information leakage can occur if scripts from one origin are exposed to images from another origin (one that isn't the same ).

To mitigate this, canvas elements are defined to have a flag indicating whether they are origin-clean .All canvas elements must start with their origin-clean set to true. The flag must be set to false if any of the following actions occur:

Whenever the toDataURL() method of a canvas element whose origin-clean flag is set to false is called, the method must immediately raise a security exception.

Whenever the getImageData() method of the 2D context of a canvas element whose origin-clean flag is set to false is called, the method must immediately raise a security exception.

3.14.12. 3.12.12 The map element

Categories
Prose Flow content .
Contexts in which this element may be used:
Where prose flow content is expected.
Content model:
Prose Flow content .
Element-specific attributes:
None, but the id name global attribute has special requirements on this element.
DOM interface:
interface HTMLMapElement : HTMLElement {
           attribute DOMString name;

  readonly attribute HTMLCollection areas;
  readonly attribute HTMLCollection images;
};

The map element, in conjuction conjunction with any area element descendants, defines an image map .

There The name attribute gives the map a name so that it can be referenced. The attribute must always be an present and must have a non-empty value. Whitespace is significant in this attribute's value. If the id attribute present on map elements. is also specified, both attributes must have the same value.

The areas attribute must return an HTMLCollection rooted at the map element, whose filter matches only area elements.

The images attribute must return an HTMLCollection rooted at the Document node, whose filter matches only img and object elements that are associated with this map element according to the image map processing model.

The DOM attribute name must reflect the content attribute of the same name.

3.14.13. 3.12.13 The area element

Categories
Phrasing content .
Contexts in which this element may be used:
Where phrasing content is expected, but only if there is a map element ancestor.
Content model:
Empty.
Element-specific attributes:
alt
coords
shape
href
target
ping
rel
media
hreflang
type
DOM interface:
interface HTMLAreaElement : HTMLElement {
           attribute DOMString alt;
           attribute DOMString coords;
           attribute DOMString shape;
           attribute DOMString href;
           attribute DOMString target;
           attribute DOMString ping;
           attribute DOMString rel;
  readonly attribute DOMTokenList relList;
           attribute DOMString media;
           attribute DOMString hreflang;
           attribute DOMString type;
};

The area element represents either a hyperlink with some text and a corresponding area on an image map , or a dead area on an image map.

If the area element has an href attribute, then the area element represents a hyperlink ; the alt attribute, which must then be present, specifies the text.

However, if the area element has no href attribute, then the area represented by the element cannot be selected, and the alt attribute must be omitted.

In both cases, the shape and coords attributes specify the area.

The shape attribute is an enumerated attribute . The following table lists the keywords defined for this attribute. The states given in the first cell of the the rows with keywords give the states to which those keywords map. Some of the keywords are non-conforming, as noted in the last column.

State Keywords Notes
Circle state circ Non-conforming
circle
Default state default
Polygon state poly
polygon Non-conforming
Rectangle state rect
rectangle Non-conforming

The attribute may be ommited. omitted. The missing value default is the rectangle state.

The coords attribute must, if specified, contain a valid list of integers . This attribute gives the coordinates for the shape described by the shape attribute. The processing for this attribute is described as part of the image map processing model.

In the circle state , area elements must have a coords attribute present, with three integers, the last of which must be non-negative. The first integer must be the distance in CSS pixels from the left edge of the image to the center of the circle, the second integer must be the distance in CSS pixels from the top edge of the image to the center of the circle, and the third integer must be the radius of the circle, again in CSS pixels.

In the default state state, area elements must not have a coords attribute.

In the polygon state , area elements must have a coords attribute with at least six integers, and the number of integers must be even. Each pair of integers must represent a coordinate given as the distances from the left and the top of the image in CSS pixels respectively, and all the coordinates together must represent the points of the polygon, in order.

In the rectangle state , area elements must have a coords attribute with exactly four integers, the first of which must be less than the third, and the second of which must be less than the fourth. The four points must represent, respectively, the distance from the left edge of the image to the top left side of the rectangle, the distance from the top edge to the top side, the distance from the left edge to the right side, and the distance from the top edge to the bottom side, all in CSS pixels.

When user agents allow users to follow hyperlinks created using the area element, as described in the next section, the href , target and ping attributes decide how the link is followed. The rel , media , hreflang , and type attributes may be used to indicate to the user the likely nature of the target resource before the user follows the link.

The target , ping , rel , media , hreflang , and type attributes must be omitted if the href attribute is not present.

The activation behavior of area elements is to run the following steps:

  1. If the DOMActivate event in question is not trusted (i.e. a click() method call was the reason for the event being dispatched), and the area element's target attribute is ... then raise an INVALID_ACCESS_ERR exception.
  2. Otherwise, the user agent must follow the hyperlink defined by the area element, if any.

One way that a user agent can enable users to follow hyperlinks is by allowing area elements to be clicked, or focussed and activated by the keyboard. This will cause the aforementioned activation behavior to be invoked.

The DOM attributes alt , coords , shape , href , target , ping , rel , media , hreflang , and type , each must reflect the respective content attributes of the same name.

The DOM attribute shape must reflect the shape content attribute, limited to only known values .

The DOM attribute relList must reflect the rel content attribute.

3.14.14. 3.12.14 Image maps

An image map allows geometric areas on an image to be associated with hyperlinks .

An image, in the form of an img element or an object element representing an image, may be associated with an image map (in the form of a map element) by specifying a usemap attribute on the img or object element. The usemap attribute, if specified, must be a valid hashed ID hash-name reference to a map element.

If an img element or an object element representing an image has a usemap attribute specified, user agents must process it as follows:

  1. First, rules for parsing a hashed ID hash-name reference to a map element must be followed. This will return either an element (the map ) or null.

  2. If that returned null, then abort these steps. The image is not associated with an image map after all.

  3. Otherwise, the user agent must collect all the area elements that are descendants of the map . Let those be the areas .

Having obtained the list of area elements that form the image map (the areas ), interactive user agents must process the list in one of two ways.

If the user agent intends to show the text that the img element represents, then it must use the following steps.

In user agents that do not support images, or that have images disabled, object elements cannot represent images, and thus this section never applies (the fallback content is shown instead). The following steps therefore only apply to img elements.

  1. Remove all the area elements in areas that have no href attribute.

  2. Remove all the area elements in areas that have no alt attribute, or whose alt attribute's value is the empty string, if there is another area element in areas with the same value in the href attribute and with a non-empty alt attribute.

  3. Each remaining area element in areas represents a hyperlink . Those hyperlinks should all be made available to the user in a manner associated with the text of the img or input element. .

    In this context, user agents may represent area and img elements with no specified alt attributes, or whose alt attributes are the empty string or some other non-visible text, in a user-agent-defined fashion intended to indicate the lack of suitable author-provided text.

If the user agent intends to show the image and allow interaction with the image to select hyperlinks, then the image must be associated with a set of layered shapes, taken from the area elements in areas , in reverse tree order (so the last specified area element in the map is the bottom-most shape, and the first element in the map , in tree order, is the top-most shape).

Each area element in areas must be processed as follows to obtain a shape to layer onto the image:

  1. Find the state that the element's shape attribute represents.

  2. Use the rules for parsing a list of integers to parse the element's coords attribute, if it is present, and let the result be the coords list. If the attribute is absent, let the coords list be the empty list.

  3. If the number of items in the coords list is less than the minimum number given for the area element's current state, as per the following table, then the shape is empty; abort these steps.

    State Minimum number of items
    Circle state 3
    Default state 0
    Polygon state 6
    Rectangle state 4
  4. Check for excess items in the coords list as per the entry in the following list corresponding to the shape attribute's state:

    Circle state
    Drop any items in the list beyond the third.
    Default state
    Drop all items in the list.
    Polygon state
    Drop the last item if there's an odd number of items.
    Rectangle state
    Drop any items in the list beyond the fourth.
  5. If the shape attribute represents the rectangle state , and the first number in the list is numerically less than the third number in the list, then swap those two numbers around.

  6. If the shape attribute represents the rectangle state , and the second number in the list is numerically less than the fourth number in the list, then swap those two numbers around.

  7. If the shape attribute represents the circle state , and the third number in the list is less than or equal to zero, then the shape is empty; abort these steps.

  8. Now, the shape represented by the element is the one described for the entry in the list below corresponding to the state of the shape attribute:

    Circle state

    Let x be the first number in coords , y be the second number, and r be the third number.

    The shape is a circle whose center is x CSS pixels from the left edge of the image and x CSS pixels from the top edge of the image, and whose radius is r pixels.

    Default state

    The shape is a rectangle that exactly covers the entire image.

    Polygon state

    Let x i be the (2 i ) th entry in coords , and y i be the (2 i +1) th entry in coords (the first entry in coords being the one with index 0).

    Let the coordinates be ( x i , y i ), interpreted in CSS pixels measured from the top left of the image, for all integer values of i from 0 to ( N /2)-1 , where N is the number of items in coords .

    The shape is a polygon whose vertices are given by the coordinates , and whose interior is established using the even-odd rule. [GRAPHICS]

    Rectangle state

    Let x1 be the first number in coords , y1 be the second number, x2 be the third number, and y2 be the fourth number.

    The shape is a rectangle whose top-left corner is given by the coordinate ( x1 , y1 ) and whose bottom right corner is given by the coordinate ( x2 , y2 ), those coordinates being interpreted as CSS pixels from the top left corner of the image.

    For historical reasons, the coordinates must be interpreted relative to the displayed image, even if it stretched using CSS or the image element's width and height attributes.

Mouse clicks on an image associated with a set of layered shapes per the above algorithm must be dispatched to the top-most shape covering the point that the pointing device indicated (if any), and then, must be dispatched again (with a new Event object) to the image element itself. User agents may also allow individual area elements representing hyperlinks to be selected and activated (e.g. using a keyboard); events from this are not also propagated to the image.

Because a map element (and its area elements) can be associated with multiple img and object elements, it is possible for an area element to correspond to multiple focusable areas of the document.

Image maps are live ; if the DOM is mutated, then the user agent must act as if it had rerun the algorithms for image maps.

3.12.15 MathML

The math element from the MathML namespace falls into the embedded content category for the purposes of the content models in this specification.

User agents must handle text other than inter-element whitespace found in MathML elements whose content models do not allow raw text by pretending for the purposes of MathML content models, layout, and rendering that that text is actually wrapped in an mtext element in the MathML namespace .(Such text is not, however, conforming.)

User agents must act as if any MathML element whose contents does not match the element's content model was replaced, for the purposes of MathML layout and rendering, by an merror element in the MathML namespace containing some appropriate error message.

To enable authors to use MathML tools that only accept MathML in its XML form, interactive HTML user agents are encouraged to provide a way to export any MathML fragment as a namespace-well-formed XML fragment.

3.12.16 SVG

The svg element from the SVG namespace falls into the embedded content category for the purposes of the content models in this specification.

To enable authors to use SVG tools that only accept SVG in its XML form, interactive HTML user agents are encouraged to provide a way to export any SVG fragment as a namespace-well-formed XML fragment.

3.14.15. 3.12.17 Dimension attributes

The width and height attributes on img , embed , object , and video elements may be specified to give the dimensions of the visual content of the element (the width and height respectively, relative to the nominal direction of the output medium), in CSS pixels. The attributes, if specified, must have values that are valid positive non-zero integers .

The specified dimensions given may differ from the dimensions specified in the resource itself, since the resource may have a resolution that differs from the CSS pixel resolution. (On screens, CSS pixels have a resolution of 96ppi, but in general the CSS pixel resolution depends on the reading distance.) If both attributes are specified, then the ratio of the specified width to the specified height must be the same as the ratio of the logical width to the logical height in the resource. The two attributes must be omitted if the resource in question does not have both a logical width and a logical height.

To parse the attributes, user agents must use the rules for parsing dimension values . This will return either an integer length, a percentage value, or nothing. The user agent requirements for processing the values obtained from parsing these attributes are described in the rendering section . If one of these attributes, when parsing, returns no value, it must be treated, for the purposes of those requirements, as if it was not specified.

The width and height DOM attributes on the embed , object , and video elements must reflect the content attributes of the same name.
